Inconel 686 Alloy 686 2.4606 Severe Environments NiCrMo Alloy Nickel Alloy Rod
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ZHEMU |
| Certification: | ISO |
| Model Number: | Standard and Customization |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5KG |
|---|---|
| Price: | As Per Quotation |
| Packaging Details: | Plywood Box |
| Delivery Time: | 25-35 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000kg per Week |
|
Detail Information |
|||
| High Light: | Alloy 686 2.4606,nickel alloy 686,NiCrMo Alloy |
||
|---|---|---|---|
Product Description
Inconel 686 Outstanding Corrosion-resistance in a Range of Severe Environments
INCONEL 686 is a single-phase, austenitic Ni-Cr-Mo-W alloy offering outstanding corrosion-resistance in a range of severe environments. Its high nickel (Ni) and molybdenum (Mo) provide good resistance in reducing conditions, and high chromium (Cr) offers resistance to oxidizing media. Molybdenum (Mo) and tungsten (W) aid resistance to localized corrosion such as pitting. Iron(Fe) is closely controlled to enhance properties. Low
carbon (C) helps minimize grain boundary precipitation to maintain corrosion-resistance in the heat-affected
zones of welded joints. Resistance to general, pitting and crevice corrosion increases with the alloying
(Cr+Mo+W) content, and INCONEL alloy 686 scores higher than competitive materials.
Inconel 686 is used for resistance to aggressive media in chemical processing, pollution
control, pulp and paper manufacture, and waste management applications.
Chemical composition
| Element | Cr | Mo | W | Ti | Fe | C | Mn | S | Si | P | Ni |
| Weight(%) | 19.0~23.0 | 15.0~17.0 | 3.00~4.40 | 0.02~0.025 | 2.0 max | 0.01 max | 0.75 max | 0.02 max | 0.08 max | 0.04 max | Rem |
Features
- Exceptional resistance to sulfuric or hydrochloric acids, and mixed acids
- Resists crevice corrosion in hot acid chlorides
- Practical immunity to chloride stress corrosion cracking
- Weldments retain high chloride pitting resistance
Applications
- Chemical process vessels
- FGD scrubbers
- Pulp bleach plant washers
- Waste management
- Weld filler for other high-nickel corrosion alloys
