Zr Pipes R60702 Zirconium Tube Pure Polished Seamless Steel Pipe Hydraulic Explosion Proof
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ZHEMU |
| Certification: | ISO |
| Model Number: | Standard and Customization |
Payment & Shipping Terms:
| Minimum Order Quantity: | Not limited |
|---|---|
| Price: | As Per Quotation |
| Packaging Details: | Plywood Box |
| Delivery Time: | 25-35 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000kg per Week |
|
Detail Information |
|||
| NAME: | Zr Pipes R60702 Zirconium Tube Specialty Application Pure Polished Seamless Steel Pipe Hydraulic Explosion-proof Tube QIYUEXIN | Wall Thickness: | 0.5-4.5mm, 0.3mm-120mm |
|---|---|---|---|
| Length: | 1-10m | Application: | Power Plant, Chemicle Equipment |
| Specification: | 6-127mm, 1.0-350mm | Standard: | ASTM B523 B523m-2012A |
| Inside Diameter: | 8-80mm, 2.0mm-219mm | Surface: | Polished |
| High Light: | Zr Pipes R60702,Polished Seamless Steel Pipe,Seamless Steel Pipe Hydraulic |
||
Product Description
Pipes R60702 Zirconium Tube Specialty Application Pure Polished Seamless Steel Pipe Hydraulic Explosion-proof Tube
| Item name | Hot sale Zr705 Zr702 zirconium tube pipe price per kg |
| Standard | ASTM B523 |
| Specification | Zr+Hf>99.2% |
| Application |
Used to make high temperature superconductive materials. Used to make electrodes components, foils, flanges bolts, tubes and rods for special applications. Used for applications in medical equipment, such as zirconium implants. Used as raw material for reactors and crucibles. |
| Surface | Polished |
| Outside Diameter | 4~114mm |
| Thickness | 0.2~10mm |
| Grade | R60702/Zr702, R60705/Zr705 |
Chemical composition
| Grade |
Zr700 (R60700) |
Zr702 (R60702) |
Zr704 (R60704) |
Zr705 (R60705) |
Zr706 (R60706) |
| Component % | |||||
| Zr+Hf(min) | 99.2 | 99.2 | 97.5 | 95.5 | 95.5 |
| Hf(max) | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 |
| Fe+Cr | 0.20(max) | 0.20(max) | 0.2-0.4 | 0.20(max) | 0.20(max) |
| Sn | - | - | - | 1.0-2.0 | - |
| H(MAX) | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 |
| C(max) | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 |
| Nb | - | 2.0-3.0 | 2.0-3.0 | ||
| O(max) | 0.10 | 0.16 | 0.18 | 0.18 | 0.16 |
Mechanical property
| Grade |
Zr700 (R60700) |
Zr702 (R60702) |
Zr704 (R60704) |
Zr705 (R60705) |
Zr706 (R60706) |
| Tensile strength min(Mpa) | - | 380 | 415 | 550 | 510 |
| Yield strength min(Mpa) | - | 205 | 240 | 380 | 345 |
| Tensile strength max(Mpa) | 380 | - | - | - | - |
| Yield strength max(Mpa) | 305 | - | - | - | - |
| Elongation min % | 2 | 16 | 14 | 16 | 20 |
| Bending radius * | 5T | 5T | 5T | 3T | 2.5T |
FEATURE:
Zirconium is a rare metal, with amazing corrosion resistance, high melting point, high hardness and strength and other characteristics, is widely used in aerospace, military, nuclear reaction, atomic energy field.
