Custom Titanium Tube Gr1 Gr2 CP Ti 2 2.5 2.75 3 Inch Titanium Pipe Intake Pipe Exhaust Pipe
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ZHEMU |
| Certification: | ISO |
| Model Number: | Standard and Customization |
Payment & Shipping Terms:
| Minimum Order Quantity: | Not limited |
|---|---|
| Price: | As Per Quotation |
| Packaging Details: | Plywood Box |
| Delivery Time: | 25-35 days |
| Payment Terms: | T/T |
| Supply Ability: | 5000kg per Week |
|
Detail Information |
|||
| Name: | Custom Titanium Tube Gr1 Gr2 CP-Ti 2 2.5 2.75 3 Inch Titanium Pipe For Intake Pipe Exhaust Pipe | Model NO.: | Titanium Tube&Pipe |
|---|---|---|---|
| Surface: | Pickled Bright Polished Satin | Standard: | ASME, AISI, ASTM, DIN, BS, JIS, GB/Customized |
| Application: | Heater, Cooler, Vaporizer, Condenser | Length: | 3,6,9,12m/Customized |
| Color: | Silver,Black,etc | Material: | Ta1,Ta2,Ta9,Ta10,Tc4,Gr.1 Gr.2 Gr.3 Gr.7 Gr.9 Gr.1 |
| Item: | Titanium Plate/Titanium Sheet | Specification: | OD: 1.5-219mm |
| Wall Thickness: | 0.016-0.5 Inch. | ||
| Highlight: | Titanium Tube Gr1,Titanium Tube Gr2,3 inch Titanium Pipe |
||
Product Description
Custom Titanium Tube Gr1 Gr2 CP-Ti 2 2.5 2.75 3 inch Titanium Pipe For Intake Pipe Exhaust Pipe
|
Name
|
Titanium Alloy Pipe Tube
|
|||
|
Characteristic
|
Excellent mechanical properties, Corrosion resistance,Light,High strength.
|
|||
|
Standard
|
ASTM B861/B861M,ASTM B338/B338M,ISO5832-2.
|
|||
|
|
Gr.1(UNS R50250,Ti-CP)/Gr.2(UNS R50400,Ti-CP)/Gr.7(UNS R52400,Ti-0.15Pd)
|
|||
|
Gr.9(UNS R56320,Ti-3Al-2.5V)/Gr.12(UNS R53400,Ti-0.3Mo-0.8Ni)/Gr.5(Ti-6Al-4V)
|
||||
|
Surface treatment
|
Pickling, polishing, mechanical treatment, electrochemical polishing
|
|||
|
|
Gr.1/Gr.2 0.016-0.5 inch (0.406-12.7mm) or customized
|
|||
|
Gr.5/Gr.9/Gr.12 0.035-0.5 inch(0.889-12.7mm) or customized
|
||||
|
Outer Diameter
|
Gr.1/Gr.2 1/8-24inch(3.175-609.6mm) or customized
|
|||
|
Gr.5/Gr.9/Gr.12 1/8-24inch(3.175-609.6mm) or customized
|
||||
Mechanical Property
Please note that these values may vary based on specific standards and size specifications. The following values are typical for reference:
|
Grade
|
Tensile Strength
|
Yield Strength
|
Elongation
|
|
|
Gr.1
|
240 Mpa
|
170 Mpa
|
24%
|
|
|
Gr.2
|
345 Mpa
|
275 Mpa
|
20%
|
|
|
Gr.5
|
895 Mpa
|
825 Mpa
|
10%
|
|
|
Gr.9
|
620 Mpa
|
483 Mpa
|
10%
|
|
|
Gr.12
|
483 Mpa
|
345 Mpa
|
12%
|
|
